WMAB WMABP
Category: Guide Post Sets | HSN: 84807900
Download Drawing
Availability:
In Stock
|
Catalog |
No. |
|
D |
A |
B |
a |
b |
d |
HI |
T |
O |
eH7 |
|
( |
A1 |
b1 |
|
Type |
PD |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
20 |
26 |
|
74 |
44 |
56 |
30 |
6.6 |
50 |
15 |
42 |
6 |
+0.012 |
56 |
28 |
15 |
|
|
25 |
31 |
|
84 |
48 |
66 |
30 |
9 |
50 |
20 |
46 |
8 |
|
66 |
33 |
15 |
|
WMAB |
32 |
40 |
-0.005 |
100 |
58 |
76 |
36 |
11 |
60 |
20 |
56 |
|
+0.015 0 |
76 |
38 |
18 |
|
WMABP |
38 |
48 |
0 |
130 |
75 |
100 |
44 |
11 |
70 |
25 |
73 |
100 |
50 |
22 |
||
|
|
50 |
60 |
|
155 |
90 |
125 |
60 |
14 |
90 |
25 |
87 |
10 |
|
125 |
62.5 |
30 |
|
|
60 |
70 |
|
190 |
120 |
150 |
80 |
18 |
100 |
30 |
117 |
13 |
+0.018 0 |
150 |
75 |
40 |
